* Hover mouse over the icon, There will be a layer that shows specific information. Click on the icon, A table will appear on the bottom to display specific information.
One Phase Input/Output
AC Normal
UPS Load: 20% ~ 80%
UPS Overload: >= 80%
UPS Load: <= 20%
Three Phase Input/Output
AC Normal
UPS Load: 20% ~ 80% [Up]:1 out [Down]: 3 out
UPS Overload: >= 80% [Up]:1 out [Down]: 3 out
UPS Load: <= 20% [Up]:1 out [Down]: 3 out
Rectifier/Inverter
Rectifier
Inverter
Battery
UPS Capacity: 0% ~ 10%
UPS Capacity: 10% ~ 90%
UPS Capacity: >= 90%
Battery Fail
Battery Unknown
With certain protocols, this tab displays "Alarm Status".
